Titanium Grade 9 Cannula Tubes
video

Titanium Grade 9 Cannula Tubes

Titanium Grade 9 tube is a titanium grade characterized by marvelous corrosion resistance to seawater and higher mechanical properties compared to stainless steels. Ti 3-2.5 tubing can be bent at room temperature using standard bend techniques. It is routinely bent on a radius of three times the actual tube diameter. Moreover, thin walled tubing requires adequate support of the ID during bending. Because of the high strength and low modulus of this alloy, springbuck is about twice that of stainless steel.
Send Inquiry
Chat Now
Product Introduction
Products Description

Titanium Grade 9 cannula tubes has advantages as bleow:

Excellent resistance to seawater corrosion

Highest mechanical strength

Excellent strength to weight ratio

Resistant to stress corrosion cracking in chloride and sour gas environments

Excellent resistance to pitting, crevice and erosion corrosion

Good formability and weldability

Very low thermal expansion



Top quality Grade 9 titanium welded pipe

extruded titanium tubing



Chemical Composition (Wt %)

  Al V Fe N O C H
Min 2.5 2.0
Max 3.5 3.0 0.30 0.02 0.12 0.05 0.0125

Gr9 titanium tubing (also known as TC3.0 or Ti-3Al-2.5V) is a titanium alloy material that is lightweight, strong, and corrosion-resistant, making it very versatile. Here are some of the main uses of Gr9 titanium tubing:
Aerospace industry: Gr9 titanium tubing is widely used in the aerospace field due to its excellent mechanical properties and corrosion resistance. It can be used to manufacture hydraulic piping systems for aircraft, engine components and other structural parts that require high strength and corrosion resistance.
Automotive and transport: Gr9 titanium tubing is also suitable for the manufacture of automobiles, motorbikes and other means of transport. It can be used for frames, exhaust pipes and other components to improve the strength and durability of vehicles. Especially in the field of racing cars, titanium tubing is favoured due to its lightweight and high strength properties.





Gnee Group has multiple subsidiaries located in Anyang, Tianjin, Zhengzhou and other regions. The group is headquartered in Anyang City, one of the eight ancient capitals of China, the hometown of Oracle and the site of the world cultural heritage "Yin Ruins". It is rapidly growing into the most professional international copper and titanium supply chain enterprise in Central China.

Team Friendly Company

bending titanium tubing



Hot Tags: titanium grade 9 cannula tubes, China titanium grade 9 cannula tubes manufacturers, suppliers, factory, 5 inch titanium pipe, Titanium Seamless Pipe, Titanium Straight Tube, Gr2 Titanium Seamless Pipe, Gr7 Titanium Round Pipe, Titanium Gr4 Straight Piping
